Leather, Shoe Making Machine, Hydraulic Swing Arm Cutting Press

Basic Info.

Model NO.	GSB-2C
Control	CNC
Certification	CE, ISO9001
Automatic Grade	Manual
Knife Type	According to Die Cutter
Customized	Customized
Condition	New
Color	Blue and Can Be Customed
After-sales Service	Engineers Available to Service Machinery Overseas
The Worktable Size	400*800mm
Max Cutting Force	16t
Transport Package	Standard Export Wooden Box
Specification	GSB-2C-160
Trademark	haide
Origin	China
Production Capacity	5000 Pieces /Year

Product Description

Product Features:1. Labor saving and simplicity of operation,lower failure rate2. Better efficiency and high speed of cutting force.3. Rocker cutting head rotates freely, the best sight in operation, convenience in choosing materials 4. Adjust the swing arm cutting stroke, operation smoothly and easily.5. Press hands button before cutting, avoid continuing abuse, high security.Product application:Shoe Helper, shoe head, upper, football, volleyball, tennis, sandpaper, medicine, plastic, foam, floor, felt, car interior, PP,PE,EVA,EPE,EPP,EPS, sponge, rubber, bubble film, double-sided glue, advertising paste, magnetic paste, insulation cotton, pearl cotton, computer accessories, paper, mat, Xuan paper, fan, seal, protective clothing, film, jigsaw puzzle, chocolate, filter material, sound-absorbing cotton, corrugated board, clean cloth, non-woven cloth, leather, seat cover, foot pad, umbrella, mouse pad, carton, cup, tablecloth, simulation flower, raincoat, hat, ear cover, mask, glove, insole, coaster Loofah cloth, blanket, cork, plaster, nuts, camouflage net, soundproof cotton, clothing, etc.Product data:

Model No.	JSB-2C-100	JSB-2C-120	JSB-2C-160	JSB-2C-200	JSB-2C-250
Cutting force	10T	12T	16T	20T	25T
Size for swing arm	380*300mm	350*400mm	350mm*400mm	350mm*540mm	450mm*540mm
Size for work table	650*330mm	400*800mm	400mm*900mm	500mm*1000mm	500mm*1000mm
Total stroke	175mm	175mm	175mm	175mm	175mm
Effective stroke	100mm	100mm	100mm	100mm	100mm
Motor Power	1.1kw	1.1kw	1.5kw	1.5kw	1.5kw
Voltage	customized	customized	customized	customized	customized

If the above table does not have the size of the cutting machine you need, we can remake it for you.
REMARK: MY FACTORY CAN MAKE THE MACHINE ACCORDING YOUR ORDER, FOR EXAMPLE, THE CUTTING FORCE, CUTTING AREA, FEEDING DEVICE, SPECIAL STROKE ETC
Product Application Case:Product picture:

Product packaging picture:
Product Certificates and Qualifications: WHY CHOOSE HAIDE MACHINERY?
1.More than 20 years experience in the field of die cutting machine.2.Strictly Quality control
(Comparing with other company Hai De has our own quality control team, every product will be checked again and again before delivery according to standard.)
3.Reasonable price and quick delivery time
(We are the directly manufacturer of cutting machine and with full experience, the price is competitive and we have our big factory working house and many experience workers can ensure the delivery time)
4.OEM and ODM service.
(We have OEM for many oversea customers and we have our own ODM team can produce product on your demand accordingly )
5.Professional salesman and good service
(All of our foreign sale man have to pass the strictly professional production knowledge training before their start to communicate with customer, and we will reply your inquiring asap no later than 24 Hours)
FAQ1. Q: Are you a factory or trading company? A: Yes,we are a factory. welcomed to visit us 2. Q: Where is your factory located? How can I visit there? A: Our factory is located in Yancheng City,China. It takes about 1 hours from Shanghai by plane3. Q: What is the lead time? A: It depends on your order quantity4. Q: Where is your Loading Port A: Shanghai. port, China or otheres as you request5. Q: What are your payment terms? A: T/T 30% deposit and balance paid before shippment.
