Basic Info.

Model NO.	AMD-357
Power Source	Hydraulic Pressure
Precision	High Precision
Certification	CE, ISO 9001
Condition	New
Hole Shapes	Round, Square, Rectangle, Kidney Shape
Sheet Moving Speed	40m/Min
Warranty	One Year
Loading	20′ot Container
Total Power	20kw
Processing Sheet Thickness	up to 6mm(Mild Steel)
Punching Frequency	300-600hpm
Electric Control System	Siemens 808d
Dimension(L*W*H)	4490*5300*2110mm
After-Sales Service Provided	Available to Service Overseas
Transport Package	Pallet, Foam and Plastic Film/Customized
Specification	CE
Trademark	AMD
Origin	Shandong China(Mainland)
HS Code	8462101000
Production Capacity	300 Sets Per Year

Product Description

China Sheet Metal Hole CNC Punching Machine for Sale

Feature:
1. Adopts Siemens 3/4 axis CNC special system and match up digital AC servo motor to make it fast and reliable;
2. Fuselage is O type Steel welding, the whole pass by tempering treatment to own good rigid and hardly deformation;
3. With the second positioning function, can achieve without dead zone processing;
4. The transmission system use the international brand with high precision, big guide the ball screw, linear guide rail are high precision and good performance;
5. Main pneumatic components, electric components, hydraulic components and transmission adopt perfectly;
6. Use AMADA standards casting integrated thick turret mold disc and standards internationally general thick molds.
Machinery main details:
1. Germany Siemens 808D System;
2. AMADA Standard 80mm Ductile Iron Thick Turret Disc;
3. Taiwan Ball Screw & Linear Guide;
4. International electrical components;
5. Secondary positioning system.

Main Technical Specification:

Specification	Unit	AMD-357
Transmission mode	/	Mechanical
Punch force	KN	250(Standard)/300
Power rating	KW	11
Processing sheet size	mm	2500*1250
Processing sheet thickness	mm	≤4
Max. Punch diameter	mm	Ø88.9
Sheet moving speed	m/min	40
Punching frequency	hpm	300
Hole accuracy	mm	±0.1
Number of stations in turret disc	No.	16/24/32
Turret rotational speed	rpm	30
Controlled axis	No.	3/4
Rotating location	No.	0/2
Air pressure	Mpa	≥0.8
Outline Dimension	mm	4490*5300*2110
Machine Weight	T	10

Notice:
According to your requirements, the most suitable machines will be designed for your workpieces, please indicate the following details.
1. Please tell us your metal sheet material.
2. The workpiece dimension (including length, width and thickness).
3. The information of hole shapes and hole diameter that you want to punch.
4. It's my pleasure if you can send some photos or drawings of your products for our reference.
Based on these details information, the detailed technical proposals will be sent to you for reference.
Warmly welcome you to visit our factory in Qingdao China.
